Commercial-Grade Weatherized Electrified Exit Device

The 10xEExERx630xCDx99 is a heavy-duty, weatherized electrified exit device built for demanding exterior and high-traffic commercial applications. Finished in 630 (US32D) Satin Stainless Steel, this device delivers corrosion resistance, clean aesthetics, and long-term durability.

Designed for secure egress and electrified latch retraction functionality, it’s ideal for schools, healthcare facilities, retail, industrial buildings, and controlled-access environments.

Available in 36" or 48" lengths to fit standard commercial door openings.

Key Features

• Weatherized construction for exterior or harsh environments

• Electrified Exit Device (EExER configuration)

• 630 / US32D Satin Stainless Steel finish

• Available in 36” or 48” lengths

• Heavy-duty commercial-grade performance

• Designed for high-traffic openings

• Corrosion-resistant stainless steel components

• Clean, professional appearance for modern facilities

Technical Specifications

• Part Number: 10xEExERx630xCDx99

• Finish: 630 / US32D Satin Stainless Steel

• Function: Electrified Exit Device with Latch Retraction

• Configuration: Weatherized (99)

• Available Sizes: 36" or 48"

• Application: Exterior & interior commercial doors

• Door Type: Metal or wood doors (standard thickness)

• Handing: Field reversible (confirm manufacturer specs if needed)

Ideal Applications

• Schools & universities

• Hospitals & healthcare facilities

• Warehouses & distribution centers

• Retail storefront exits

• Government buildings

• Controlled-access commercial doors

Compatibility Notes

• Compatible with access control systems using electrified latch retraction

• Designed for integration with power supplies and controllers rated for electrified exit hardware

• Recommended for use with properly rated power transfer devices (EPT / door loops)

• Ensure proper voltage and amperage requirements per manufacturer specifications

(Always verify power supply compatibility before installation.)

Built for Real-World Installations

This isn’t light-duty hardware. The 10xEExERx630xCDx99 is built to withstand exterior exposure, frequent use, and demanding commercial environments — while maintaining smooth, reliable operation.

Install it once. Trust it for years.

(NOTE: A Logic Controller is required for EE ER but not included in standard package.)

Important Weatherization Note

The standard 10 Series platform is available in weatherized configurations for certain Detex electrified functions, but Detex currently lists EE ER delayed egress with latch retraction as a non-weatherized electrified option.

For an exterior or weather-exposed opening, contact Detex or specify the appropriate system, such as:

• WDEx10 – Weatherized delayed-egress system

• ER EX W – Weatherized electric latch retraction with Request-to-Exit

Do not assume a standard EE ER device is weatherized simply because the underlying 10 Series platform has weatherized versions.

Important Ordering Information

Before ordering, verify:

• 10 Series rim application

• EE ER delayed-egress/latch-retraction function

• 36" or 48" device

• 630 brushed stainless finish

• CD cylinder dogging

• 99 surface strike

• Controller requirements

• Access-control requirements

• Automatic-operator requirements

• Fire-alarm interface

• Door and frame preparation

• Interior versus weather-exposed installation

Controller/power supply, Remote Indicating Unit, access-control equipment, automatic operator, outside trim, and other accessories are not included with the exit device unless specifically stated.
