Build or repair a commercial access-control opening with the Adams Rite 7400A UltraLine Electric Strike Body Kit, designed for standard jamb and single-door applications.

The 7400A is the core electric strike body used with several Adams Rite 7400 Series modular faceplate kits, allowing installers to configure the strike for different aluminum, hollow metal, and wood door-frame preparations without replacing the strike body.

This listing is for the electric strike body kit only. The required faceplate kit is selected separately according to the existing jamb preparation.

Key Features

• Genuine Adams Rite 7400A

• UltraLine electric strike body

• Designed for standard jamb applications

• Intended primarily for single-door openings

• Part of the modular Adams Rite 7400 Series

• Preload-capable electric strike design

• Field-selectable Fail-Secure / Fail-Safe

• Multiple voltage capability

• Compact commercial-grade strike body

• Adjustable keeper design

• Non-handed operation

• Compatible with multiple Adams Rite faceplate kits

• Ideal for new installations, repairs, and retrofit applications

• Faceplate sold separately

• No architectural finish designation required for the body kit

Product Specifications

Manufacturer: Adams Rite
Series: UltraLine 7400 Series
Model: 7400A
Product Type: Electric Strike Body Kit
Application: Standard Jamb / Single Door
Faceplate: Sold Separately
Handing: Non-Handed
Operation: Electrically Released
Function: Field Selectable Fail-Secure / Fail-Safe
Voltage Capability: 12, 16 or 24 VAC/DC
Application Type: Commercial Access Control

Modular Electric Strike System

The Adams Rite modular packaging system separates the electric strike body from the architectural faceplate.

The 7400A provides the operating mechanism, while the appropriate faceplate kit determines how the completed strike fits the door-frame preparation.

This makes the 7400A particularly useful for:

• Replacement installations

• Access-control retrofits

• Maintaining common replacement inventory

• Changing faceplate configurations without replacing the strike body

• Servicing existing Adams Rite UltraLine strikes

Compatible Faceplate Kits

The 7400A can be paired with the following Adams Rite faceplate kits:

FPK7400

Standard 1-1/4" x 4-7/8" flat faceplate configuration.

Used to create the standard Adams Rite 7400 UltraLine Electric Strike.

FPK7410

Extended 7-15/16" faceplate for applicable commercial frame preparations.

FPK7411

Extra-long 10-1/4" faceplate for applications requiring additional coverage.

FPK7430

Conversion-style faceplate for compatible aluminum jamb applications.

FPK7440

Square-corner faceplate configuration for steel and wood jamb applications.

FPK7445

Conversion faceplate designed for certain existing Adams Rite 4901 and 4501 strike preparations.

Important Faceplate Note

A faceplate is required to create a complete electric strike assembly.

The 7400A body kit does not include an architectural faceplate. Select the appropriate FPK faceplate based on:

• Existing jamb preparation

• Door and frame material

• Required faceplate dimensions

• Existing strike cutout

• Architectural finish

Preload-Capable UltraLine Design

The UltraLine platform is engineered to provide dependable electric release even when pressure is being applied against the door.

Preload may be caused by:

• HVAC pressure

• Building pressure

• Weatherstripping

• Door closer pressure

• Door warping

• Minor alignment issues

This makes the UltraLine platform particularly suitable for demanding commercial access-control openings.

Fail-Secure / Fail-Safe Operation

The strike body can be configured for the required operating mode.

Fail-Secure

The strike remains locked when electrical power is removed and releases when energized.

Fail-Safe

The strike releases when electrical power is removed.

Always select the operating mode required by the access-control design and applicable building or life-safety code.

Ideal Applications

• Aluminum storefront doors

• Hollow metal frames

• Commercial wood frames

• Office buildings

• Retail facilities

• Schools and universities

• Healthcare facilities

• Government buildings

• Commercial access-control systems

• Existing UltraLine electric strike repairs

• Retrofit access-control projects

What's Included

• Adams Rite 7400A Electric Strike Body Kit

Not Included

• Faceplate kit

• Architectural faceplate

• Lip extension

• Lock or deadlatch

• Access-control reader

• Power supply

• Door hardware not specifically listed

Important Ordering Information

Before ordering, verify:

• Existing jamb preparation

• Required faceplate kit

• Existing latch and lock type

• Voltage requirements

• Door and frame configuration

• Required architectural finish

For standard jamb / single-door applications, use the 7400A.

For radiused stile applications involving pairs of doors, use the Adams Rite 7401A body kit.
