Provide reliable electronic door-release control with the Alarm Controls TS Series Request-to-Exit Push Button Stations, a versatile family of commercial-grade switches designed for compatible access-control and electrified door systems.

Manufactured by Alarm Controls, an ASSA ABLOY company, the TS Series offers a wide selection of mechanical push-button stations for commercial offices, warehouses, hospitals, schools, industrial facilities, storefronts, and institutional buildings.

Available configurations include illuminated square and rectangular buttons, large mushroom push buttons, narrow-stile switches, vandal-resistant controls, electronic timers, pneumatic timers, and specialized emergency door-release stations.

Selected models feature illuminated push buttons, red and green status LEDs, stainless steel wall plates, and normally open/normally closed electrical contacts for integration with commercial magnetic locks, electric strikes, and access-control controllers.

Choose momentary switching for temporary door-release activation, latching operation for maintained control, or adjustable timed outputs for applications requiring an unlock interval.

With mounting options for standard single-gang electrical boxes and narrow aluminum storefront frames, the Alarm Controls TS Series provides practical control solutions for professionally installed commercial electronic locking systems.

Key Features

• Commercial Request-to-Exit Operation: Allows users to activate compatible electronic door-release equipment by pressing a push button.

• Multiple Button Designs: Mushroom, square, rectangular, and vandal-resistant push buttons available.

• Illuminated Button Options: Selected models include high-brightness LED illumination.

• Stainless Steel Faceplates: Durable 430 or 302 stainless steel plates, depending on model.

• Momentary Switching: Standard models offer spring-return button action.

• Latching Options: Selected models provide maintained alternate-action switching.

• Electronic Timer Options: Adjustable timed outputs are available on selected models.

• Pneumatic Timer Options: Models TS-15 and TS-16 provide mechanical time delay without requiring power for the timer.

• SPDT & DPDT Switching: Contact configurations vary by model.

• Status LED Options: Red, green, or combined indicators available on selected stations.

• 12/24V Illumination Options: Compatible voltage configurations are available for illuminated models.

• Single-Gang Mounting: Suitable for compatible standard commercial electrical boxes.

• Narrow-Stile Mounting: Selected models fit 1-3/4-inch-wide plates for storefront and mullion applications.

• Vandal-Resistant Models: Heavy-duty push-button configurations available for demanding environments.

• ADA-Symbol Options: Selected blue-button models feature a wheelchair accessibility symbol.

• Emergency Release Options: Specialized models offer maintained activation with an audible warning.

• UL 294 Listings: Applicable to selected manufacturer-listed TS models.

• Commercial Access-Control Compatibility: Integrates with appropriately designed electromagnetic locking and door-control equipment.

• Custom Configurations: Selected button colors, plate finishes, legends, and contact arrangements may be available by special order.

Standard TS Series Models

TS-1 – Green Mushroom Request-to-Exit Button

The Alarm Controls TS-1 features a large 1-1/2-inch green mushroom push button with red and green LED status indicators.

Specifications:

• SKU: TS-1

• Button: 1-1/2" Green Mushroom

• Plate: Single-Gang Stainless Steel

• Faceplate Marking: PUSH TO EXIT

• Switch: Momentary, One N/O and One N/C Contact

• Contact Rating: 10A at 35V DC or 120V AC

• Indicators: 1/4" Red and Green LEDs

• LED Voltage: 12/24V AC/DC

• Switch Depth: 2-1/2" Behind Plate

• Options: TS-1L Latching, TS-1R Red Button

TS-2 – Illuminated Green Square Exit Button

The Alarm Controls TS-2 is a single-gang request-to-exit station with a large illuminated green square button.

Specifications:

• SKU: TS-2

• Button: 2" Green Square

• Marking: PUSH TO EXIT

• Plate: Single-Gang 430 Stainless Steel

• Switch: Momentary SPDT

• Contact Rating: 10A at 35V DC or 120V AC

• LED Voltage: 12/24V AC/DC

• Switch Depth: 1-1/2"

• Options: TS-2-2 DPDT, TS-2T Electronic Timer, TS-2R Red Button, alternate legends

TS-3 – Illuminated Exit Button with Red Status LED

The Alarm Controls TS-3 adds a separate 1/2-inch red status LED to the illuminated green push-button configuration.

Specifications:

• SKU: TS-3

• Button: 2" Illuminated Green Square

• Plate: Single-Gang Stainless Steel

• Marking: PUSH TO EXIT

• Switch: Momentary SPDT

• Contact Rating: 10A at 35V DC or 120V AC

• Additional Indicator: 1/2" Red LED

• LED Voltage: 12/24V AC/DC

• Options: TS-3-2 DPDT, TS-3T Timed Output

TS-4 – Illuminated Blue ADA-Symbol Exit Button

The Alarm Controls TS-4 is a single-gang exit station with an illuminated blue square button featuring the wheelchair accessibility symbol.

Specifications:

• SKU: TS-4

• Button: 2" Blue Square

• Marking: Wheelchair Accessibility Symbol

• Plate: Single-Gang Stainless Steel

• Switch: Momentary SPDT

• Contact Rating: 10A at 35V DC or 120V AC

• LED Voltage: 12/24V AC/DC

• Options: TS-4-2 DPDT, TS-4T Electronic Timer

TS-5 – Blue ADA-Symbol Button with Red Status LED

The Alarm Controls TS-5 includes the illuminated blue accessibility-symbol button along with a separate red LED status indicator.

Specifications:

• SKU: TS-5

• Button: 2" Blue Square

• Marking: Wheelchair Accessibility Symbol

• Plate: Single-Gang Stainless Steel

• Switch: Momentary SPDT

• Contact Rating: 10A at 35V DC or 120V AC

• Additional Indicator: 1/2" Red LED

• LED Voltage: 12/24V AC/DC

• Options: TS-5-2 DPDT, TS-5T Timed Output

Compact Rectangular Push-Button Models

TS-6 – Single-Gang Exit Button with Red & Green LEDs

The TS-6 features a compact illuminated green rectangular push button with separate red and green status LEDs.

• SKU: TS-6

• Mounting: Single Gang

• Plate: 430 Stainless Steel

• Button Size: 5/8" x 7/8"

• Switch: Momentary DPDT

• Contact Rating: 3A at 35V DC or 120V AC

• Indicators: Red and Green LEDs

• Switch Depth: 1-1/4"

• Options: TS-6L Latching, TS-6T Timed

TS-7 – Single-Gang Compact Exit Button

The TS-7 uses a compact illuminated green rectangular button without the separate red and green status indicators found on the TS-6.

• SKU: TS-7

• Mounting: Single Gang

• Button Size: 5/8" x 7/8"

• Switch: Momentary DPDT

• Contact Rating: 3A at 35V DC or 120V AC

• Button Illumination: Included

• Options: TS-7L Latching, TS-7T Timed

TS-8 – Narrow-Stile Exit Button with Red & Green LEDs

The TS-8 provides the same general control and indication features as the TS-6 in a compact narrow-stile configuration.

• SKU: TS-8

• Mounting: 1-3/4" Narrow Stile

• Plate: 302 Stainless Steel

• Button Size: 5/8" x 7/8"

• Switch: Momentary DPDT

• Contact Rating: 3A at 35V DC or 120V AC

• Indicators: Red and Green LEDs

• Options: TS-8L Latching, TS-8T Timed

TS-9 – Narrow-Stile Compact Exit Button

The TS-9 is a narrow-stile version of the TS-7 with an illuminated green rectangular push button.

• SKU: TS-9

• Mounting: 1-3/4" Narrow Stile

• Plate: 302 Stainless Steel

• Button Size: 5/8" x 7/8"

• Switch: Momentary DPDT

• Contact Rating: 3A at 35V DC or 120V AC

• Options: TS-9L Latching, TS-9T Timed

Electronic Time-Delay Options

Selected TS Series stations include an electronic timed-output relay.

These models are useful for properly designed applications requiring a controlled release interval rather than a basic momentary switch activation.

Available Models

• TS-2T: Illuminated green square button, electronic timer

• TS-3T: Green square button, red status LED, electronic timer

• TS-4T: Blue ADA-symbol button, electronic timer

• TS-5T: Blue ADA-symbol button, red status LED, electronic timer

• TS-6T / TS-8T: Rectangular button with additional LED indicators and timed output

• TS-7T / TS-9T: Rectangular illuminated button with timed output

Timer Specifications

• Typical Adjustable Duration: Approximately 2–45 seconds, depending on model

• TS-4T and TS-5T Published Range: 2–44 seconds

• Electronic Timed Contact Rating: 2A at 35V DC on the listed square-button timer models

• LED Voltage: Model Dependent

• Extended Mounting Depth: Timed square-button versions require approximately 2-1/2" behind the plate

Additional timed-output arrangements, such as dual timed contacts and separate momentary/timed contacts, are available under distinct manufacturer part numbers.

Important: These timers control the station's electrical output duration. They are not automatically equivalent to listed delayed-egress systems.

Pneumatic Time-Delay Models

TS-15 – Narrow-Stile Pneumatic Exit Button

• SKU: TS-15

• Mounting: 1-3/4" Narrow Stile

• Plate: 302 Stainless Steel

• Button: 1/4" Push Button with Guard Ring

• Timer: Pneumatic, Adjustable 2–60 Seconds

• Contacts: Isolated N/O and N/C

• Published AC Rating: 10A at 125/250V AC

• Timer Power: No External Electrical Power Required

• Switch Depth: 1-1/4"

TS-16 – Single-Gang Pneumatic Exit Button

• SKU: TS-16

• Mounting: Single Gang

• Plate: 430 Stainless Steel

• Button: 1/4" Push Button with Guard Ring

• Timer: Pneumatic, Adjustable 2–60 Seconds

• Contacts: Isolated N/O and N/C

• Published AC Rating: 10A at 125/250V AC

• Timer Power: No External Electrical Power Required

• Switch Depth: 1-1/4"

• Option: TS-16302 Weather-Resistant Plate

The TS-15 and TS-16 use a mechanical pneumatic timing mechanism rather than an electronic timer circuit.

Vandal-Resistant TS Series Models

Alarm Controls also offers heavy-duty exit stations designed for demanding commercial and industrial applications.

TS-10 & TS-11

• 3/4" Vandal-Resistant Push Button

• TS-10: Single-Gang Plate

• TS-11: Narrow-Stile Plate

• Red and Green LED Indicators

• Momentary DPDT Contacts

• Contacts Rated 10A at 35V DC

• Timed Configurations Available

• TS-10302 Weather-Resistant IP65 Option

TS-12 & TS-13

• 3/4" Vandal-Resistant Push Button

• TS-12: Single-Gang Plate

• TS-13: Narrow-Stile Plate

• Momentary DPDT Contacts

• Contacts Rated 10A at 35V DC

• Timed Configurations Available

• TS-12302 Weather-Resistant IP65 Option

TS-23

• Single-Gang Stainless Steel Plate

• 3/4" Vandal-Resistant Push Button

• EXIT Faceplate Marking

• Momentary DPDT Switching

• Contacts Rated 10A at 35V DC

Emergency Door Release Models

TS-25 – Single-Gang Emergency Door Release

The TS-25 is a specialized emergency-release station with maintained switching and an audible alarm.

TS-26 – Narrow-Stile Emergency Door Release

The TS-26 offers the same general emergency-release functions in a narrower wall-plate configuration.

Shared Features:

• EMERGENCY DOOR RELEASE ALARM WILL SOUND Marking

• Alternating-Action DPDT Switch

• Illuminated Push Button

• 85 dB Piezo Buzzer

• 12/24V AC/DC Operation

• Contacts Rated 3A at 35V DC or 120V AC

These models should be selected according to the approved emergency-egress design and applicable installation requirements.

Recommended Applications

• Commercial Office Buildings

• Warehouse and Distribution Facilities

• Industrial and Manufacturing Buildings

• Hollow Metal Commercial Doors

• Aluminum Storefront Entrances

• Secured Employee Entrances

• Schools and Universities

• Hospitals and Healthcare Facilities

• Assisted Living Facilities

• Government and Institutional Buildings

• Commercial Access-Control Systems

• Magnetic-Lock Release

• Electric-Strike Control

• Reception and Security Stations

• Commercial Door Security Upgrades

• Electronic Door-Release Retrofits

Operating Functions

Momentary Operation

Pressing a momentary TS switch changes its electrical contact state.

Releasing the push button returns it to its original condition.

Latching Operation

A latching or alternate-action model maintains its switched state after the button is released.

Another activation changes the state again.

Electronic Timed Release

Timed models activate their designated output for a configured interval following button activation.

The connected controller or lock circuit determines the resulting door-release behavior.

Pneumatic Timed Release

Pneumatic models use a mechanical timing mechanism to maintain contact operation for the configured time without requiring separate electrical power for the timer.

LED Indication

Selected models include separate status LEDs that can be connected to compatible control or monitoring circuits.

These LEDs require suitable electrical connections and do not automatically indicate magnetic bond or door position without appropriate external equipment.

Installation & Compatibility

The Alarm Controls TS Series should be installed by qualified commercial door hardware and access-control professionals.

Before installation:

• Select the correct switch function and contact configuration.

• Verify available wall-plate mounting space.

• Confirm the required electrical box depth.

• Check contact ratings against connected equipment.

• Supply the correct voltage to illuminated buttons and LEDs.

• Use the proper additional resistor where required for 24V operation.

• Connect timed outputs and status indicators according to the specific model's wiring diagram.

• Verify the required release behavior for the opening.

• Test all normal and emergency operating conditions.

Important Installation Information

• TS model specifications vary substantially.

• The entire series does not share one universal contact rating or LED voltage.

• Not every model is illuminated.

• Not every model includes separate status indicators.

• Standard momentary versions do not automatically provide a timed output.

• Latching models should not be substituted for momentary exit controls without confirming the system requirements.

• Pneumatic and electronic timers are different products.

• Selected models are UL 294 listed; verify certification for the actual part number.

• ADA-symbol faceplates do not independently establish compliance with all accessibility requirements.

• A push-to-exit station alone does not guarantee code-compliant electromagnetic-locking or emergency-egress operation.

• Where required, use approved independent release devices, fire-alarm interfaces, and appropriate mechanical egress hardware.

• Standard models should not be assumed weatherproof.

• Install according to manufacturer instructions and the applicable Authority Having Jurisdiction.

Why Choose Alarm Controls TS Series?

The Alarm Controls TS Series Request-to-Exit Stations offers a wide range of reliable mechanical switching solutions for commercial electronic door control.

From illuminated square buttons and compact narrow-stile stations to vandal-resistant, electronically timed, pneumatic, and emergency-release configurations, the TS family allows installers to select the correct function for each application.

With durable stainless steel construction, model-specific SPDT and DPDT contacts, visual status options, and compatibility with properly designed electronic locking equipment, the Alarm Controls TS Series provides practical solutions for professional commercial access-control installations.
